Kyocera KD235GX-LPB太阳能电池板

KYOCERA's Advanced Cell Processing

This technology and automated production facilities have produced a multi-crystalline solar cell with an efficiency of over 16%. All modules are constructed using a tempered glass front, EVA pottant and a PVF backing to provide maximum protection from the severest environmental conditions.The entire laminate is framed in a
重型阳极氧化铝框架提供结构强度和易于安装。由于Kyocera模块如此高效，所以需要更少的空间，而不是其他同样的太阳能模块。该转化为每平方英尺和较低的安装结构成本。

KYOCERA has perfected its new surface treatment technology and is introducing it on a new line of modules named d.Blue, for its dark blue color.

The newly developed treatment method processes multi-crystalline silicon cells in order to produce a surface texture that minimizes surface reflectance and maximizes output.The result is a maximum conversion efficiency of 16%, one of the highest conversion efficiencies in the polycrystalline module industry.
D.Blue是在所有类型的系统中安装的理想选择，从住宅网格领带到SCADA和大型
规模商业系统。

D.Blue模块可在整个Kyocera系列中提供。
The KD205GX-LP features an industry high 20-year power output warranty

• 高效多晶模块
• The KD235GX-LPB modules have a +5/-3% power tolerance
• 细胞效率超过18.5％
• UL listed
• 低铁，钢化玻璃，EVA密封剂和阳极氧化铝框架结构
• 20 year output warranty on all KD Series modules
• Weather resistant junction box or Multi Contact connectors
